Xinzhongsen is the Heavy Duty Gas Spring Operated Double Bike Storage Rack manufacture and supplier in China. We have specialized in the field of bicycle parking for many years, our bike parking products have won wide acclaim from customers in Europe, America and other regions for their high quality and excellent performance. We would be delighted to offer you a quotation on any upcoming project.
Model Number: F-QLH30-LR; D-70mm-LB
Product Origin: China
Payment: T/T, L/C
Shipping Port: Xiamen
Heavy Duty Gas Spring Operated Double Bike Storage Rack is made of Aluminum alloy and comes with high quality, it is the most technologically advanced bike rack on the market. Designed to stand out for ergonomic design and quietness, is also suitable for larger and heavier bikes, reducing the theft by the lock ring on the rack.
| Product Name | Heavy Duty Gas Spring Operated Double Bike Storage Rack |
| Model Number | F-QLH30-LR；D-70mm-LB |
| Material | Pillar, lifting rack: Aluminum alloy |
| Measurements |
Vertical lifting rack:L:1970 * W:220 * H:1820 （mm） Sliding bike rack: L:1570 * W:115 * H:720 （mm） |
| Colors | Light grey or customized |
| Capacity | 1 bike per upper rack |
| Loading |
Vertical lifting rack: 22 to 30KG; Sliding bike rack: Below 40KG |
| Mount | fixing to floor using expansive anchor bolts. |
| Installation Angle | 10° or customized |
| Recommended Ceiling Height | 2500mm |
| Maintenance | Minimal maintenance required |
Heavy Duty Gas Spring Operated Double Bike Storage Rack is totally different from any bike rack on the market. It is one of the highest density bike parking solutions on the market. The innovative and space-saving design is perfect for bike parking lots, subway and train stations, campus, or anywhere parking efficiency needs to be maximized.
Most traditional two-tier bike racks require users to pull the upper tier out and into the aisle, which can lead to traffic jams. The upper tier of the Heavy Duty Gas Spring Operated Double Bike Storage Rack is designed to lift vertically, while the bottom tier of the racks slides from side to side, allowing for extremely compact parking while allowing the upper tier to move up and down. It's user-friendly, space-saving provide a more friendly experience for users.
Advantages of the Heavy Duty Gas Spring Operated Double Bike Storage Rack
-Stability and security
-Suitable for indoor and outdoor use
-Space efficient high-capacity bicycle parking
-Accommodates most types of bikes
-Locking ring for the theft prevention
-Easy maintenance.
Green cycling and storage
-Recyclable and environmentally friendly materials
Installation
The Heavy Duty Gas Spring Operated Double Bike Storage Rack can be installed at the angle of 10°，30°，45° to accommodate different situations , particularly useful for sites with narrow aisles.
Upper Vertical lifting rack: Angle 10°-Centre to centre distance of 60cm;
We take pleasure in guiding you through the layout of your available space, ensuring that the parking area is both highly efficient and seamlessly accessible.
Delivery
Current lead time is 7-9 weeks from receipt of your written purchase order. Extra time may be needed if extensive customization is required.
The upper vertical lift bike rack and lower sliding rack of our bike rack system are designed to function independently, offering you the flexibility to select and purchase additional models that best align with the specific requirements of your project. Should you require a more tailored solution or have any inquiries about customization, please feel free to reach out to us at your convenience. We are always here to assist you with any detailed program or further information you may need.
